Feature
• Precision-crafted cast aluminum shell
Streamlined appearance, lightweight cast aluminum powder-coated shell, excellent heat dissipation, strong corrosion resistance.
• Integrated structure, great integrity
The pump head and the driver are integrated, easy installation.
• Seven-inch large screen, clear at a glance
A seven-inch color LCD touch screen with wide viewing angles, making operation simple.
• Servo motor drive
High-precision operation, high torque, low noise.
• Five working modes
Offers flow mode, volume mode, time dispensing mode, programming mode, and external control mode, flexibly meeting various scenario requirements.
• Multiple sensing technologies
Lid opening stop function, leak detection stop function (optional), enhancing safety.
• Intelligent interconnection, collaborative operation
Supports RS485 communication, compatible with Modbus protocol.
• Three-level user permission management, security protection, no need to worry about parameter tampering.
• Selects top-brand raw materials, meticulously selected, quality guaranteed.
• Equipped with KL series pump heads, featuring observation windows and mechanical locks, enhancing safety.
• With a patented calibration method, shortens the time by three times compared to conventional operations, reducing liquid usage by three times.
Flexible Tube Model And Flow Parameters
| Pump Head | Speed | Tube Material | Tube | Max Flow（L/min） |
| KL40 Pump Head |
50rpm | Silicone | 187# | 3.85L/min |
| 186# | 2.25L/min | |||
| 150rpm | Silicone | 187# | 12.35L/min | |
| 186# | 6.85L/min | |||
| 265rpm | Silicone | 187# | 20.85L/min | |
| 186# | 12.35L/min |
Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure, in actually using it is effected by specific factors such as pressure, medium etc. Above for reference only.
Technical Parameter
Flow range: 7-20000mL/min
Speed range: 0.1-265rpm
Speed resolution: 0.1 rpm
Speed accuracy: ＜±0.2%
Delay start time: 1S-999 H
Timing: 1S-999 H
Working time: 0.1-99.99S
Dispensing time: 1～999,“0” Infinite loops
Dispensing interval time: 0.1-999 S/Min/H/D
Reverse Angle: 0-720 degrees
External control signal input: (1) Start/Stop: passive contact, external control input level (5~24V)
(2) Forward/Reverse: passive contact, external control input level (5~24V)
(3) Speed Regulation: analog 0~5V, 0~10V, 4~20mA can be set.
External control signal output: (1) Start/Stop: Level Signal (following input voltage)
(2) Forward/Reverse: Level Signal (following input voltage)
Communication interface: RS485, RS232, Ethernet, Modbus protocol is available, profibus communication (optional)
Power supply: AC 100-240V 50Hz-60Hz
Power consumption: <180W
Working environment: Temperature 0 ～ 40℃, relative humidity＜80%
Shell material: Aluminum
IP grade: IP66/IP67
Dimension (L×W×H): 370*265*295 mm
Drive Dimension (L×W×H): 278*265* 295 mm
Weight: 20kg
MF118 Applicable Pump Head and Tube,Speed, Flow
| Drive Type | Pump Head | Channel | Tube | Single Channel Flow Rate（mL/min) |
| MF118 | KL40 | 1 | 187#186# | 7~20000mL/min |
Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure,
in actually using it is effected by specific factors such as pressure, medium etc. Above for reference only.
Dimension(mm)
Statement：The final explanation right of above information belongs to Lead Fluid.
