Function and Feature
• Primarily composed of silicone rubber.
• Colorless and transparent, with a hardness of 60A (96410), other hardness options available are 50A. Excellent breathability, UV grade B, ozone grade D.
• Temperature range is -50 to 230 degrees Celsius.
• Sterilization methods: high-temperature high-pressure, gamma radiation.
• Comply with USP Class VI, FDA and NSF related standards. The biocompatibility of Tygon3350 can reach ISO10993 standard.
Tygon 3350 Specifications
| Tubing Material | Tubing No. | ID×OD×Wall(mm) | Standard Package(m) |
3350 |
13# | 0.8×4×1.6 | 7.5 |
| 14# | 1.6×4.8×1.6 | 15 | |
| 19# | 2.4×5.6×1.6 | 15 | |
| 16# | 3.2×6.4×1.6 | 15 | |
| 25# | 4.8×8×1.6 | 15 | |
| 15# | 4.8×9.6×2.4 | 15 | |
| 17# | 6.4×9.6×1.6 | 15 | |
| 24# | 6.4×11.1×2.4 | 15 | |
| 18# | 7.9×11.1×1.6 | 15 | |
| 35# | 7.9×12.7×2.4 | 15 | |
| 36# | 9.6×14.4×2.4 | 15 | |
| 73# | 9.6×16×3.2 | 15 | |
| 82# | 12.7×19.1×3.2 | 15 |
Applications:
Non-corrosive, for weak acid and base liquid transfer, used in industries such as food, beverages, cosmetics, biotechnology, and pharmaceuticals.,etc.
