Function and Feature
• High-quality pneumatic motor drive, quiet and stable operation, safe and reliable.
• Throttle valve stepless speed, wide flow range.
• Integrated desktop structure, easy to install and operate.
• Suitable for liquid transmission with general accuracy requirements.
• High protection level, can adapt to more complex working environment.
Remark：Customizable stainless steel shell
Technical Parameters
- Pump head: YZ35
- Flow range: 2000～13000mL/min
- Speed range: 150～600rpm
- Adjust Speed: Throttle valve stepless speed
- Control Function: Start-stop (standard), reversing function（optional）
- Gas supply pressure: 0.1～0.7Mpa
- Inlet pipe: 6.5×10mm PU
- Gas consunption: ≤0.3m³/min
- Environment: Temperature 0 ～ 40℃, relative humidity＜80%
- IP grade: IP31
- Shell material: Metal anticorrosive spray (standard), 304SS (optional)
- Dimension（L×W×H）: 309×316×237mm
- Drive weight: 11.5KG
FG601S-Q Peristaltic pump applicable pump head, tubing and flow rate
|
Drive model
|
Pump head
|
Channel
|
Tube
|
Flow rate（mL/min）
|
|
FG601S-Q |
YZ35
|
1
|
73#82#
|
2000～13000
|
Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure, in actually it is effected by specific factors such as pressure, medium, etc. Above for reference only.
Dimension（mm）
Statement：The final explanation right of above information belongs to Lead Fluid.
