Functions and Features
•Industrial grade AC frequency conversion explosion-proof motor (ExdIIBT4), with special pump head, safe and reliable.
•External frequency conversion control, with functions such as adjust speed, start-stop,reversible direction, analog adjust speed, RS485 communication.
•Stepless speed, speed range 72rpm～600rpm, speed resolution 2rpm.
•Split design, the driver is separated from the frequency conversion, suitable for a variety of working environment.
•Install a variety of pump heads and tubes.
•IP55, suitable for complex working environmen.
•The standard frequency conversion is not explosion-proof and cannot be placed in a flammable and explosive environment.
Remark:
1. Industrial grade explosion-proof frequency conversion is optional .
2. Customizable all-in-one model.
Specifications
Pump Head: YZ15/YZ15T,YZ25,YT15,YT25,KZ25,KZ25-L
Flow range: 4～6000mL/min
Speed range: 72～600rpm
Speed resolution: 0.1HZ(corresponding speed 2rpm)
Adjust speed: Frenquency converter steppless speed （standard frequency converter motor without connection cable）
Control function: Adjust speed, start/stop, reversible direction, analog speed control, RS485 communication
Speed accuracy: <±3%
Power supply: 3 phase 380V 50Hz
Power consumption: 0.55KW
Working condition: Temperature 0 ～ 40℃, relative humidity＜80%
Anti-explosion grade: ExdIIBT4
IP grade: IP55(motor)
Dimension (L×W×H): 462×330×422mm
Weight: 37Kg
FG600S-A3 Suitable Pump Heads and Tubing, Flow parameters
| Drive Type | Pump Head | Channel | Tube | Single Channel Flow Rate(mL/min) |
| FG600S-A3 | YZ15/YZ15T | 1~4 | 13#14#19#16#25#17#18# | 4～2479 |
| YT25 | 1~4 | 15#24#35#36# | 120～2900 | |
| KZ25/KZ25-L | 1~2 | 15#24#35#36# | 177～6000 |
Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure,in actually using it is effected by specific factors such as pressure, medium etc. Above for reference only.
Dimension(mm)
